Movable bottom system：

The chassis is welded with hot-dip galvanized square pipe, and the welding joint is treated with imported zinc-rich paint. The chassis has support legs and can be height adjusted to adjust the level of the coop. The chassis is provided with a bridge and tires, and the front end is provided with a traction device, which can be connected with a special power machinery to achieve movement, and a hand jack can adjust the height of the traction device.

Insulation frame system：

Insulation board using EPS sandwich board, B1 fireproof sandwich, unit weight 20KG/m³, fireproof thermal insulation.

Feeding and drinking system:

The interior is equipped with a water line and the front section is equipped with a filtration system. The inside is provided with auger line, and the material feeding method is hand-operated. There is a hopper in the operation area. After feed transfer, the feed is transported to the feed pan by shaking the end rotating shaft through auger to achieve feeding.

Egg collecting system：

Egg nest, tailstock, egg collecting table.

The eggs in the egg nest are transported to the egg collecting table through the egg belt by hand-shaking.

Manure removal system:

The bottom is covered with a manure belt, the front and rear drive, and the upper end is covered with slat floor, which is also used to achieve the manure removal by hand-driven active roller.

Ventilation system：

Both sides of the chicken coop are provided with ventilation windows, using the straight open type, can control the opening angle, adjust the ventilation volume, according to the specific scene can increase the exhaust fan.

Perching system:

Make full use of the three-dimensional space, effectively increase the breeding density, provide a perch for roosting, to meet the behavioral habits of chickens perched high.

Welfare door system：

Equipped with a ladder, convenient for chickens to enter and exit, to provide free movement space.
